Case study

Camera development focused on stable image quality and detection

A vision camera case study covering sensor and optics selection, camera circuit design, edge processing and integration into the platform.

Challenge

Stable image quality and repeatable detection

Stable image quality and repeatable detection performance were required. To achieve this, conditions such as resolution, frame rate and operating environment had to be aligned early in development.

Approach

From aligning requirements to design for mass production

  1. 01

    Aligning requirements early

    At the start of development we aligned resolution, frame rate, field of view (FOV), latency, interfaces and operating environment conditions.

  2. 02

    Sensor and optics selection

    We selected the image sensor and the optics, such as lenses, to match the requirements.

  3. 03

    Camera circuit and edge processing

    We designed the camera circuit and implemented edge processing and integration into the platform.

  4. 04

    Design for mass production

    We designed the camera so that the same quality can be reproduced in mass production.

Results

A camera platform ready for mass production and rollout

Sensor and optics suited to the application

A sensor and optics configuration that matches the requirements was established.

Shorter tuning cycles

The cycle needed for image quality tuning was shortened.

Real-time data interface

The camera has an interface that handles image data in real time.

Ready for mass production

The design is ready to move into mass production.

Extensible platform

A base that can be extended as applications grow.

Predictable deployment

Introduction and rollout became easier to plan.

Each case study gives an outline within the limits of our confidentiality obligations.
