Case study

An HMI integrated into one platform

A smart display case study in which display, touch, processing, communication and power were integrated into a single HMI platform.

Challenge

Bringing several elements together in one product

Display, touch, processing, communication and power had to be brought together as a single HMI platform. In addition, the product had to support specifications that differ from market to market.

Approach

Development starting from system-level targets

  1. 01

    Setting system targets

    We started from targets for the whole system: screen size, resolution, brightness, touch and latency.

  2. 02

    Integrated design

    We designed display, touch, processing, communication and power as one unit.

  3. 03

    Manufacturability and evaluation

    We designed with manufacturability in mind and confirmed operation through evaluation.

  4. 04

    Documentation and configuration management

    We managed market-specific variations through documentation and configuration management.

Results

An integrated design that supports rollout market by market

Integrated HMI platform

Display, touch, processing, communication and power were combined into one platform.

Specifications that follow the targets

The specifications were defined starting from the targets for size, resolution, brightness, touch and latency.

Designed with mass production in mind

Manufacturability was considered so that the design leads smoothly into mass production.

Support for market variations

With configuration management in place, market-specific differences in specifications are handled systematically.

Each case study gives an outline within the limits of our confidentiality obligations.
